Product Details
Certification: RoHS, ,ISO, CE, SGS
Payment & Shipping Terms
Model NO.: |
DS |
Type: |
Cooling Fan |
Electric Current Type: |
AC |
Mounting: |
Ceiling Fan |
Transport Package: |
Wooden |
Specification: |
16-24FT, 50rpm, 1.5KW, Diameter 5-7.3 Meter |
Trademark: |
DAISEN |
Origin: |
China, Chengdu |
HS Code: |
8414591000 |
Customization: |
Available |
Material: |
Aluminum Fan |
Blade Material: |
Al-Mg Alloy |
Model NO.: |
DS |
Type: |
Cooling Fan |
Electric Current Type: |
AC |
Mounting: |
Ceiling Fan |
Transport Package: |
Wooden |
Specification: |
16-24FT, 50rpm, 1.5KW, Diameter 5-7.3 Meter |
Trademark: |
DAISEN |
Origin: |
China, Chengdu |
HS Code: |
8414591000 |
Customization: |
Available |
Material: |
Aluminum Fan |
Blade Material: |
Al-Mg Alloy |
| Model | Fan diameter | Motor power | Max speed | Rated voltage | Air volume | Max coverage | Weight | Noise |
| DS-7.3 | 7.3M(24FT) | 1.5KW | 50rmp | 220V/380V | 14800M3/min | 1200m3 | 126KG | ≤60db |
| DS-6.7 | 6.7M(22FT) | 1.5KW | 55rmp | 220V/380V | 13600M3/min | 1000m3 | 123KG | ≤60db |
| DS-6.1 | 6.1M(20FT) | 1.5KW | 55rmp | 220V/380V | 12900M3/min | 800m3 | 119KG | ≤60db |
| DS-5.5 | 5.5(18FT) | 1.5KW | 55rmp | 220V/380V | 12200M3/min | 600m3 | 116KG | ≤60db |
* Standard universal mount compatible with most common industrial building structures
* Up to 240Nm of torque for easier and more stable high air volume output
* The fan blade handle is flexibly connected to release high-frequency vibration, and there is no metal fatigue for long-term operation
* Comply with CCC, CE, UL and other international standards, and key components have passed safety testing
* Industrial-grade safety product requirements, long-term stable operation in harsh and harsh environments
Features of Traditional HVLS Fans
